Motor
Medium-Duty 12V DC, automatic thermal
protection, permanent lubrication
More Value Less Parts
• No more Cable Tension Monitor means
faster and easier installation
Mechanics
▪ Steel chassis and Plastic Cover
▪ Internal Chain and Sproket Drive Mechanism
(63:1 Gear Reduction)
▪ Auto-Force Adjustment for Changing Weather
and Environmental Conditions
▪ DC Wi-Fi logic with built-in Bluetooth and
surge suppressor
• Up to 850lbs lift capacity
Power
120V AC, 60 Hz voltage, 1.5A current rating,
UL Listed, 6' power cord (3-prong)
Speed
8.5" per second upward, 7.6" per second downward
Lighting
myQ remote LED Light - 1,500 lumens
Dimensions
• Opener head: 21.5" H x 7.5" W x 7.9" L
• Max. Door Height: 14ft.
• Max. Door Width: 18ft
• Headroom clearance required:
3in from Center of Torsion Bar
• Max. Door Weight: 850lbs
Warranties
Lifetime: Motor
5 Year: Parts
1 Year: Battery and Accessories
Security+ 2.0
Radio controls:
Operating range ~200'; Operating temperature:
-31o
F to 149o
F; 3-Button Remote Control (893MAX),
Remote Control Code Format: Security+ 2.0, premium
remote control; Garage Door Opener Code Format:
Security+ 2.0; Anti-burglary coding.
Encrypted controls:
Smart Control Panel (880 LMW), Timer-to-Close,
Program Remote Controls, Keypads and myQ
accessories, Maintenance Alert System,
Easy Wi-Fi Setup.
myQ Radio
902-928 MHz 50-Channel FHSS (frequently
hopping spread spectrum); Provides 2-way
communication from garage door opener
and myQ accessories; enables monitoring
and control of garage door openers via
smartphone or tablet.
HomeLink® compatible (version 4.0 or higher)
May require an external adapter depending
on the model and year of vehicle. Visit
HomeLink.com for additional information.
