The Linear Multi-Code 3089 is a single button remote used to operate a garage door opener or gate. The Multi-Code 3089 uses 10 binary (two position) switches giving you 1024 coding options. This remote uses 300 MHz Multi-Code format.
Compatible with Linear Multi-Code 300 MHz receivers.
Includes:
Single button remote
Visor clip
9V battery
Instructions
Dimensions: 3" X 1 3/4" X 9/16"
Specifications:
Model: 308911
Order Number: MCS308911
UPC: 093863118562
FCC ID: EF4 XMULTI-CODE
Canada RSS/CNR210: 1078 102 1578
The Linear Multi-Code 3089 will work if you use any of the following radio controls:
Chamberlain: 300MC
Keystone Heddolf: M220
Linear: 109020, 109920, 109950, 302101, 302210, 302850, 306010, 307010, 308301, 308911, 412001, 414001, 420001
Transmitter Solutions: 300MCD21K, 300MCD21V, 300MCD22K, 300MCD22V, EMP300MCD21V, FFII300MCD21K
Warranty: one year
How to Program a Linear Multi-Code Remote 3089
1. Push down and in with both thumbs on the bottom front of the remote to slide to bottom cover off. This may not be easy to do. You can also use a coin or flat head screw driver to pop the bottom cover off using the tab on the bottom of the remote.
2. Locate the 10 switch code on the receiver or working remote. Your garage or gate will have an external receiver that will have the 10 switch code in it. If you have a working remote it is usually easier to use the switches from the remote.
3. Move the switches in the new remote so they are in the same order as the receiver or working remote.
4. Press the remote. The garage or gate should operate. If the remote does not work then reverse all the switches.
